Name: EN 853 2SN Hydraulic Hose
Brand: Canka
Price: 1 USD

Place of Origin : Qingdao

Brand Name : Canka

Model Number : EN 853 2SN

Price : 0.43-6.6 USD

Packaging Details : Seaworthy packing film

Delivery Time : one month

Payment Terms : FOB

Supply Ability : 300000 meters

MOQ : 2000 meters

Contact Now

CONSTRUCTION: This hose consists of an inner tube of oil syntheric rubber,two wires braid reinforcement,and an oil and weather resistant synthetic rubber cover.
APPLICATIONS: Hose range suitable to carry bydraulic fluids such as glycol,mineral oils、fuels、lubrication、emulsion、 hydrocarbons etc.
WORKING TEMPERATURE: From-40℃ up to +100℃
Nominal Diameter∮		Inside Diameter∮	Reinforcement Diameter∮	Outside Diameter∮	Working Pressure		Proof Pressure	Burst Pressure	Bend Radius
inch	dash	mm	mm	mm	bar	psi	bar	bar	mm
3/16	5	4.6-5.4	10.6-11.7	13.3-14.1	415	6017.5	996	1660	90
1/4	6	6.2-7.0	12.5-13.1	14.4-15.2	400	5800	960	1600	100
5/16	8	7.7-8.5	14.2-14.8	16.3-17.1	350	5075	840	1400	115
3/8	10	9.3-10.1	16.2-16.8	18.3-19.1	330	4785	792	1320	130
1/2	12	12.3-13.5	19.4-20.0	21.5-22.3	275	3987.5	660	1100	180
5/8	16	15.5-16.7	22.8-23.4	25.0-25.8	250	3625	600	1000	200
3/4	19	18.6-19.8	26.4-27.2	28.6-29.4	215	3117.5	516	860	240
1	25	25.0-26.4	33.9-34.7	36.5-37.1	165	2392.5	396	660	300
1-1/4	31	31.4-33.0	42.8-43.6	45.3-46.1	125	1812.5	300	500	420
1-1/2	38	37.7-39.3	49.2-50.0	51.7-52.5	90	1305	216	360	500
2	51	50.4-52.0	61.9-62.7	64.4-65.2	80	1160	192	320	630
